Focusrite Scarlett 16i16 Audio Interface (USB)
16-in, 16-out USB audio interface with two 4th Gen Scarlett mic preamps.
Guildwater Gear is an Authorized Focusrite Dealer. If you have any questions about this product please do not hesitate to contact us.
Scarlett 16i16 is the 4th generation of industry-leading USB audio interfaces for artists and producers; including RedNet converters, two Focusrite mic preamps, and an array of innovative workflow tools. Scarlett 16i16 is the ideal interface for artists to record and create. It has pro-grade converters taken directly from Focusrite’s RedNet range and two 4th Gen mic preamps with an impressive 69dB of gain, capable of capturing the most dynamic performances. Auto Gain and Clip Safe modes take care of levels so you can focus on the take. Scarlett 16i16 is the perfect hub to integrate your DAW and hardware with enough analogue and digital I/O to connect external instruments, processors, and effects, and manage complex routing with incredible ease via Focusrite Control 2 software.
FEATURES
16 inputs and 16 outputs; including two mic preamps, line, instrument, and MIDI I/O: Fully equipped for demanding project studios with ADAT and SPDIF I/O
4th Gen pre-amps with 69dB of gain. The legendary preamps now have even more gain and are remote controllable
Auto Gain and Clip Safe modes. 16i16 can automatically manage levels so engineers can focus on capturing the performance
Re-engineered Air mode with Presence and Harmonic Drive. Analogue circuitry and onboard DSP emulate the sound of studio consoles and the classic ISA
Low latency monitoring. Direct routing and six internal mixers to send audio wherever you need to in super-low latency
24-bit, 192 kHz conversion with 122dB of dynamic range. The same AD/DA converters as Focusrite’s flagship RedNet range
Focusrite Control 2 software and mobile app. Instantly set up mixes and manage levels on your computer, or remotely from a mobile device
Two powerful custom-designed headphone amps. Engineer and artist can independently monitor with high-quality playback on any headphones
A/B speaker switching. Essential for serious project studios with multiple monitor rigs and control rooms
Dynamic metering for input and outputs. Get instant visual indication of your input and output levels from the hardware
Included production software. Comes with Pro Tools Intro+ for Focusrite, Ableton Live Lite, six months of FL Studio Producer Edition, and a suite of instruments, processors, and effects
Easy Start tool. Get up and running immediately with Focusrite’s driver installation and getting started tool
The producer’s Scarlett. Featuring converters taken directly from Focusrite’s broadcast-ready RedNet range, Scarlett 16i16 is the industry-leading USB audio interface for project studios. It features 16 inputs and 16 outputs — including two mic preamps, Hi-Z instrument and line inputs, ADAT, SPDIF, and MIDI.
Capture every detail. The 4th Generation preamps offer an impressive 69dB of headroom, so you can capture the most dynamic performances. With a total of six analogue inputs, you have ample connectivity for outboard gear. Powerful outputs ensure clean, ultra-low distortion playback; plus, two brand new custom-designed headphone amps which can drive high-impedance headphones.
Class-leading audio quality. The Scarlett 16i16 incorporates completely revamped audio circuitry, equipped with the same professional-grade 24-bit, 192kHz converters found in Focusrite’s RedNet range, used in top recording studios and broadcast facilities worldwide. Experience unparalleled clarity with 122dB of dynamic range to capture everything from a whisper to a jet engine.
Enhance your sound with Air mode. Re-engineered Air mode takes your sound’s unique character and brings it to the front of the mix, adding musical presence or rich harmonic drive to vocals and acoustic instruments; replicating the sound of driving a classic studio console.
Auto Gain: Work faster. Designed to assist engineers of all levels, Auto Gain sets the optimal recording levels for any inputs in just a few seconds, getting you ready to record in moments. For more complex setups, multi-channel Auto Gain adjusts levels for multiple microphones, either directly on the interface or through the Focusrite Control 2 mobile and desktop applications.
Clip Safe: Never lose a take. With Clip Safe actively monitoring levels up to 96,000 times per second, Scarlett 16i16 automatically adjusts gain to prevent clipping so you avoid introducing any unwanted artefacts from hard limiting. Never miss a crucial take, especially in high-pressure recording environments such as live shows and location recordings.
Easy control with desktop and mobile app. Use the software, Focusrite Control 2, to manage routing and levels, monitor mixes, and control other features of Scarlett 16i16. The desktop software, plus apps for iOS and Android, enable engineers and performers to adjust monitor mixes and multiple mic pre gains remotely — especially useful in live rooms.
Industry-leading production software. The 4th generation Scarlett 16i16 comes with Pro Tools Intro+ for Focusrite, Ableton Live Lite, six months of FL Studio Producer Edition, and a whole host of software instruments, processors, effects, and royalty-free samples from some of the biggest names in the business. Discover some of the best-loved studio tools on the planet for writing, recording, mixing, and mastering:
Antares® Auto-Tune® Access
Klevgrand Korvpressor
Klevgrand REAMP
Softube® Marshall® Silver Jubilee 2555
Native Instruments® MASSIVE
Sonnox VoxDoubler
Landr Studio, plus five free masters
Brainworx® bx_console Focusrite SC
Focusrite Red 2 & 3 Plug-in Suite
XLN Audio® Addictive Keys
XLN Audio® Addictive Drums 2: Studio Rock
Relab’s LX480 Essentials
Splice Sounds
Effortlessly set up your Scarlett. Focusrite’s Easy Start web tool will get 16i16 up and running with zero effort, helping you locate the drivers, take you through the installation process, and direct you towards the included software.
IN THE BOX? Scarlett 16i16 / External Power supply / USB Cable
Enjoy three years of warranty. Wherever you happen to be in the world, you can rely on a three-year warranty if any Focusrite hardware needs repairing or replacing due to a manufacturing fault.
SPECIFICATIONS
Number of Microphone Preamps: 2
Phantom Power: Yes (Independent)
Instrument Inputs: 2
Line Inputs: 6
Air Mode: Yes
Auto Gain: Yes
Clip Safe: Yes
Line Outputs: 4
Headphone Outputs: 2
ADAT Inputs: 1
ADAT Outputs: 1
SPDIF Input: 1
SPDIF Output: 1
MIDI Input: 1
MIDI Output: 1
Loopback: Yes
Connectivity: USB Type-C
Protocol: USB 2.0
Form Factor: Desktop
Simultaneous I/O: 18 x 18 (including Loopback)
A/D Resolution: 24-bit/192 kHz
Bus Powered: Yes 3A
Software Compatibility. Scarlett 16i16 is class compliant so will work with Mac, Windows PC, Chromebook, and USB-C iPad.
Power Requirements. USB-3.0 Bus power 5V @3A 15W || External power supply: 5V @ 3A (included)
