MOTU 8M Audio Interface (Thunderbolt / USB)
24-input Thunderbolt audio interface with 48-channel mixing and AVB networking capability. MOTU interfaces can be found in studios around the world because of their superb performance record and trusted reliability. The 8M is one of several next-generation, high-performance audio interfaces, combining incredible audio, large console style mixing, and state-of-the-art features.
Eight pristine mic inputs with individual preamps - These mic inputs are packed with extras. The eight mic/guitar inputs are equipped with pristine, transparent preamps and offer individually adjustable 48V phantom power and -20dB pad. Preamp gain can be adjusted directly on the front panel, or from the web app control software running on your computer, tablet or smart phone. Mic inputs can be operated individually or in stereo pairs, as needed.
Superb audio quality - Pure sound, without compromise. The 8M employs latest-generation ESS Sabre32 Ultra converters, known for their industry-leading performance, together with expertly engineered analog circuits that reflect more than three decades of pro audio engineering expertise. The result? The 8M achieves actual, measured performance of 123dB dynamic range (A-weighted, 20Hz to 20kHz) on its balanced TRS analog outputs.
Thunderbolt technology - Plug-and-play ease with massive bandwidth. Thunderbolt lets you connect displays, hard drives, and other peripherals to your computer, along with the8M, and the Thunderbolt bus won't even break a sweat. But more importantly, Thunderbolt gives you an astonishing 256 channels of computer I/O (128 in and out). You can use them to route audio to the physical inputs and outputs on the 8M, plus the 48-channel mixer inside the 8M, plus audio network streams. The 8M is one of the first and only interfaces to combine Thunderbolt I/O connectivity with AVB audio networking.
Audio class compliant USB 2.0 - Broad compatibility with future-proof connectivity. Don't have a Thunderbolt-equipped computer yet? Hi-speed USB 2.0 provides across -the-board compatibility with pretty much all laptops and desktop computers. The 8M is USB audio class compliant, which means you enjoy OS-level USB compatibility and support, including iPad support (works with camera connection kit, sold separately). Since USB 2.0 devices are compatible with USB 3.0-equipped hosts, your 8M interface is a future-proof investment in your studio.
Features
Audio Quality
- Max bit depth: 24-bit
- Max sampling rate: 192kHz
Inputs
- Total inputs: 24
- Mic preamps: 8
- XLR/TRS combo jacks: 8
- XLR only jacks: 0
- 1/4" only jacks: 0
- S/PDIF in: 0
- ADAT/optical in: 16
- RCA in: 0
Outputs
- Total outputs: 26
- XLR out: 0
- 1/4" out: 8 (TRS balanced)
- S/PDIF out: 0
- ADAT/optical out: 16
- RCA out: 0
Other Connectivity
- Computer connection: Thunderbolt & USB 2.0
- MIDI I/O: No
- Headphone output(s): 1
- Word-clock I/O: No
Onboard Features
- Platform compatibility: Mac & Windows
- Phantom power: Yes
- Direct monitoring: Yes
- Onboard DSP: Yes
- Metering: LED meters
- Display: Yes
- Latency control: Yes
- Monitor control: Yes
- Headphone control: Yes
Get the ultimate in flexibility and audio performance!
