  • Sale
  • $349.99

PreSonus Monitor Station 2 (4-Channel)
Desktop Studio Control Center

Equip your studio with pro monitoring features for a song. Manage multiple audio sources and sets of monitor speakers, track using illegally loud headphone amplifiers, and talk back to your drummer—all from your desktop. Quickly and easily audition multiple stereo sources and switch between three sets of reference monitors, all from your desktop. This professional desktop studio-control system manages three stereo line-level sources, a stereo S/PDIF digital input, three sets of monitors, and four sets of headphones. Easily manage multiple sources and monitor speakers from your desktop with three sets of stereo, line-level inputs, a stereo S/PDIF digital input, and three pairs of speaker outputs. You also get Main Mute, Mono, and Dim; main and cue outs; four loud headphone amplifiers; and a talkback mic.

Consider your sources. - Switch quickly and easily between up to four audio sources with a selection of input types. ​Manage Your Destinations. - Audition your music with your choice of three stereo pairs of speaker outputs, each with separate level control. Four screaming-loud headphone outs and a talkback mic ensure your musicians hear every note—and your instructions—clearly. Customize your system for the way you work. - There’s more to managing a monitoring system than I/O, level controls, and talkback. The Monitor Station V2 offers powerful options that allow you to configure it for the way you like to work. Take control of your monitor system. - With its ergonomic, intuitive layout; extensive features and I/O; and PreSonus’ famed sound quality, Monitor Station V2 provides a versatile, convenient, and affordable solution for managing your studio monitoring system from your desktop. So sashay down to your PreSonus® dealer and take control of your monitoring system the way the professionals do!

 Features

  • 4 stereo input pairs into three selectable analog sources
  • 3 stereo pairs of individually selectable speaker outputs with level controls
  • Stereo S/PDIF digital input (44.1/48/88.2/96 kHz)
  • Stereo Main and Cue outputs
  • Large Main level control
  • Cue section with Source select, input- and output-level control
  • Main Mute, Mono, and Dim switches with variable Dim attenuation
  • 8-segment color LED input meters with selectable reference level
  • 4 screaming-loud stereo headphone amplifiers with level controls and independent source selection
  • Built-in electret-condenser talkback microphone with input-gain control and Talkback button

Technical Specifications

Audio Inputs

  • Internal Talkback Microphone
  • Gain Range:     +15 to +55 dB
  • Type:    Electret condenser
  • Sensitivity:       -42 dB

Stereo 1 and Stereo 2 Inputs

  • Type:   ¼” TRS Active Balanced
  • Input Impedance (Balanced):  10 kΩ
  • S/N Ratio (1 kHz @ +10 dBu, Unity Gain): >105 dB
  • THD+N (unwtd, 1 kHz @ 0 dBu Output, Unity Gain): <0.0075%
  • Frequency Response (±0.5 dB):  10 Hz to 65 kHz
  • Noise Floor (20 Hz to 20 kHz, 150Ω input termination): -96 dBu
  • Maximum Input Level (Minimum Gain, 1 kHz @ 0.5% THD+N): +22 dBu

Auxiliary Inputs

  • Type:  RCA Active Unbalanced
  • Input Impedance:  47.5 kΩ
  • S/N Ratio (1 kHz @ 0 dBu, Unity Gain):  >115 dB
  • THD+N (unwtd, 1 kHz @ 0 dBu Output, Unity Gain): <0.01%
  • Frequency Response (±0.5 dB): 10 Hz to 50 kHz
  • Gain Range:     80 dB to +10 dB

S/PDIF

  • Types:  RCA 75Ω coax
  • Dynamic Range: 113 dB
  • THD+N: 0.0025% (1 kHz @ -1 dBFS)
  • Maximum output at 0 dBFS:   +18 dBu
  • Sample Rates:  44.1, 48, 88.2, 96 kHz

Input Meters (ST1, ST2, and Aux only)

  • Type: Dual 8-segment LED w/peak hold
  • Sensitivity Range: -24 dB to 0 dB

Audio Outputs

  • Type:  ¼” TRS Active Balanced
  • Output Impedance (Balanced): 51Ω
  • THD+N (unwtd, 1 kHz @ 0 dBu, Unity Gain):  <0.01%
  • Frequency Response (±0.5 dB):  10 Hz to 50 kHz

Speaker A, B, and C

  • Trim Range: -80 dB to 0 dB
  • Main Level Range: -80 dB to 0 dB
  • Dim Attenuation Range: -30 dB to -6dB

Cue

  • Cue Level Range: -80 dB to 0 dB
  • Dim Attenuation (Talkback activated):  -20 dB

Headphones

  • Type:    ¼” TRS Active Stereo
  • Maximum Output (60Ω load): 150 mW / channel
  • Frequency Response (±1.0 dB):  10 Hz to 50 kHz

Power

  • Power Supply Type: External DC Transformer/Internal Line
  • Input Connector Type: Barrel, 5.5 mm outside diameter, 2.1 mm inside diameter
  • Monitor Station Input Voltage Range: 18 VDC
  • Power Requirements (Continuous): 10W

Physical Dimensions

  • Height: 2.5” (63.5 mm)
  • Depth:  8.5” (216 mm)
  • Width:  9” (228.6 mm)
  • Weight: 6 lbs. (4.54 kg)
