WesAudio Phoebe Analog Preamp with Digital Recall (500-Series)
_Phoebe NG500 Class A preamplifier with digital recall. The most notable style of Microphone preamplifiers now integrated with a digital workflow. Dual amp vintage design with most demanded modern features! We are proud to present _PHOEBE – NG500 fully analog, Class A microphone/line/instrument preamplifier with digital recall. Audio signal is processed only via analog components!
FEATURES
- 100% analog microphone/line preamp with +28dBu of headroom.
Class A fully analog – inspired by famous British design based on dual amp topology.
- Microphone gain up to 75dB.
- Carnhill Transformers (input and output).
- Output signal metering on the front panel with clip detection.
- Phantom power and phase invert control.
- Switchable impedance input (1200/300Ohm).
- All controls/analog settings are fully manageable via the WesAudio GCon DAW plug-in.
- 15dB OUTPUT PAD – passive output attenuation circuit with 1 dB step. (after the output transformer).
- Front panel XLR/TS socket which supports – HiZ instrument input (TS), line input (XLR), microphone input (XLR).
- Recallable signal source to be either back XLR Socket, or front panel XLR/TS socket.
SPECIFICATIONS
| Frequency response |
+/- 0.5dB 20Hz-20kHz; -3dB at 50kHz |
| Distortion |
0.005% at 1kHz at +20dBu output |
| Line input impedance |
5.5k ohm bridging |
| Microphone input impedance |
300/1200 ohm |
| Noise |
unity gain (better than -100dbU) Max gain +75dB (better than -70dbU) |
| EIN |
better than -120dB |
| Max power consumption |
170mA(+16V); 100mA(-16V) |
| Unit dimensions |
38x133x145mm |
| Box dimensions |
105x162x234mm |
| Unit weight |
1 kg |
| Box weight |
1,2 kg |
| Warranty |
2 years |
